Input: 16 Channel AHD/ CVI / TVI / Analog (BNC) + 4 Channel IP (Over Network)

Output: VGA: 1280×1024

HDMI: 1920×1080

CVBS (Can be used as Spot)

16CH AHD / CVI / TVI / Analog + 4CH IP

AHD/CVI/TVI: 1080P Lite

FPS:400 (PAL) / 480 (NTSC)

Max.25/30FPS Per Channel

Resolution:960×1080 (PAL/NTSC)

AHD/CVI/TVI: 1080P Lite

FPS:400 (PAL) /480 (NTSC)

Resolution:960×1080 (PAL/NTSC)

AHD/CVI/TVI: 720P

FPS:400 (PAL) / 480(NTSC)

Resolution:1280×720 (PAL/NTSC)

Analogue: 960H

FPS:400(PAL) / 480(NTSC)

Resolution: 960×575 (PAL) / 960×480 (NTSC)

Resolution: 1080P

FPS: 100(PAL) / 120(NTSC)

16 Channel Simultaneously

Input: 1 Channel (RCA)
Output: 1 Channel (RCA)
2 Way audio

1 x SATA (Up to 8TB)

2 x USB2.0

RJ-45: 100Mbps

1 x RS485
Protocol: CoC/Pelco DP/Samsung/Visca (IP Over ONVIF)
